Features:
1. 002 HELP ARM SYSTEM
2. The unique trapezoid chassis provides a strong support for tire changing.
3. The bead breaker is adjustable in four positions.
4. Integrated Power Unit-- Adopt high efficiency gear transmission:
Turntable Speed Improvement
Longer service time
Powe saving
Loss reduced
Noise reduced
Specification |
Air supply pressure |
8-10bar (116-145 psi) |
Optional power supply |
110v (1ph)/ 220v (1/3ph)/380v(3ph) |
Motor power |
0.37 kw |
Noise Level |
≤75 dB |
Product |
Semi-automatic |
Product Code |
G-22 |
External clamping |
12~26"(+Jaw's protector for 12”) |
Internal clamping |
15~28" |
Max.wheel diameter |
1120mm(44")
|
Max.wheel width |
406mm(16") |
Max. Rotating Torque |
1078 Nm |
N/G weight |
350/420 kg(771/926 lbs) |
Package dimension |
1250*1100*2000mm (49*43.3"*78.7") |
